13000L Dongfeng 4X2 Refueling Truck With Fuel Dispenser

Upper configuration

1-Tank volume:13m³(can be made into 1 or 2 compartments)

2-Tank material:carbon steel (Aluminum alloy/stainless steel are available for selection.)

3-The whole set of European configurations for each compartment: European type manhole, overflow probe system, vapor recovery system, bottom valve, API adaptors.
4-Emergency bottom valve and foldable aluminum handrail.
5-You can choose to install different brands of fuel dispensers.
6-Tank color: customized.

Product Name： 13000L Dongfeng 4X2 Refueling Truck With Fuel Dispenser
Chassis brand： Dongfeng Liuqi
Driver： flat one and a half rows
Drive wheel： 4X2

Product Features

Brief Introduction of Oil Truck

Oil tanker truck, also known as refueling truck, oil transport truck, or tanker truck. Tank trucks belong to the tank truck series of specialized vehicles, mainly used for the transportation and storage of petroleum derivatives such as gasoline, diesel, crude oil, lubricants, and coal tar.

A refueling truck is a vehicle used for transporting and delivering oil materials. It is equipped with a movable refueling machine that delivers fuel to oil receiving equipment such as vehicles, agricultural machinery, boilers, construction machinery, and hotels.

Main Parameter

Product Name	13000L Dongfeng 4X2 Refueling Truck With Fuel Dispenser
Chassis brand	Dongfeng Liuqi
Driver	flat one and a half rows
Drive wheel	4X2
Steering wheel	Left/Right hand drive
Seat capacity	2-3 person
Engine Brand	Yuchai
Engine Model	YCS06245-60A
Horse Power (HP)	145
Engine displacement	6.23L
Emission standard	Euro 6 (option:Euro3/4/5)
Wheel base	4700(mm)
Gearbox	8 forward gears and 1 reverse gear
Front wheel track	1916,1956,2046(mm)
Rear wheel track	1860,1800(mm)
Approach angle/departure angle	20/11(°)
Front/rear suspension	1445/2305(mm)
F/R axle load	6500/11500
Axle numbers	2
Tire Specification and Quantity	275/80R22.5, 6 with a spare
Vehicle dimension	8450×2530×3150(mm)
Tank dimension	5700×2000×1400(mm)
Gross vehicle weight(Kg)	18000(Kg)
Curb weight(Kg)	7585,7520(Kg)
Rated weight(Kg)	10285(Kg)
Tank volume	13cubic meter
Tank material	carbon steel/aluminum alloy/stainless steel
Standard configuration	Including a high flow oil pump, one lower loading and unloading oil valve, one oil and gas recovery valve, one oil and gas recovery interface, one set of pneumatic combination switches, one anti overflow probe rod, and one socket, one European standard tank cover, and one subsea valve,
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
