SAlC Hongyan 6X4 30 ton Dump Truck

Chassis configuration:

1.Engine: ltaly CURSOR

2.Transmission type: 8-speed gearbox

3.Wheelbase: /(mm)

4.Tyre: 12.00R20, 10+1 spare

5.Other:Flat proof, single sleeper, radio, air seat, A/C

Product Name： SAlC Hongyan 6X4 30 ton Dump Truck
Driving Type： 6x4
Dump body Volume(cbm)： 18
Rated payload weight(kg)： 30000

Product Features

SAlC Hongyan 6X4 30 ton Dump Truck

A dump truck, also known as atippertruck, refers to a vehicle that unloads goods on its own by hydraulic or mechanical lifting. Also known as a dump truck. It consists of components such as car chassis, hydraulic lifting mechanism, cargo compartment, and power take-off device.

The compartments of dump trucks are divided into two types: backward tilting and lateral tilting. The piston rod movement is controlled by the control system, and backward tilting is more common. Pushing the piston rod causes the compartment to tilt, while a few tilt in both directions.

Product parameters

Product Name	SAlC Hongyan 6X4 30 ton Dump Truck
Driving Type	6x4
Dump body Volume(cbm)	18
Rated payload weight(kg)	30000
Overall Dimension(mm)	8500x2430x3400
Dump body size(mm)	5400X2300X1400
Engine brand & model	ltaly CURSOR
Engine type	4 stroke,water-cooled, straight line 6 cylinders, diesel
Axle Quantity	3
Transmission Type	8-speed gearbox
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	12.00R20, 10+1 spare
Cab	Flat proof, single sleeper, radio, air seat, A/C
Dump body material	High strength manganese steel
Main configuration	1.Side plate 6mm, floor plate 8mm 2. Front mounted hydraulic lifting cylinder.
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
