Dongfeng 10 Ton Dump Truck

Chassis brand Dongfeng

Product origin China, Hubei

Delivery time around 10 working days

Supply capacity 1500 units one year

10 ton dump truck is mainly used for loading and unloading soil, sand, ore and loose materials. Dongfeng 10 ton dump truck belongs to medium duty dump truck, is suitable for small-scale sand field.

10 ton dump truck can automatically backward tip over to unload at a certain angle, greatly saves unloading time and labor, ,improves production efficiency, and reduces transportation cost

Product Name： Dongfeng 10 Ton Dump Truck
Driving Type： 4X2
Dump body Volume(cbm)： 11
Rated payload weight(kg)： 10000-15000

Product Features

Dongfeng 10 Ton Dump Truck

10 ton dump truck is also called 10 ton tipper truck, 10 ton dumper truck, is used to transport kinds of sand, soi, rock, ore, etc material

Product feature

Dongfeng Cummins engine 190hp

Dump box adopt China high strength manganese steel. strong and sturdy;

10 ton loading capacity

Factory direct sale

Product parameters

Product Name	Dongfeng 10 Ton Dump Truck
Driving Type	4X2
Dump body Volume(cbm)	11
Rated payload weight(kg)	10000-15000
Overall Dimension(mm)	7200x2300x3200
Dump body size(mm)	4500x2200x1100
Engine brand & model	DONGFENG Cummins & B190 33
Engine type	4 stroke,water-cooled, straight line 6 cylinders, diesel
Axle Quantity	2
Transmission Type	FAST 8 forwards,1 reverse gear, manual
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	10.00R20, 6+1 spare
Cab	Flat proof, single sleeper,radio,AC
Dump body material	High strength manganese steel
Main configuration	1.Side plate 4mm, floor plate 5mm 2. Middle double hydraulic lifting cylinder.
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
