FAW 30 Ton Tipper Truck

Chassis brand FAW

Product origin China, Hubei

Delivery time around 10 working days

Supply capacity 1,500 units one year

Tipper truck is often operated in conjunction with excavators, loaders, belt conveyors, etc. to form a loading, transporting, and unloading production line for loading and unloading soil, sand, and loose materials.

Faw tipper truck can automatically tip backward to unload at a certain angle.

FAW tipper truck greatly saves unloading time and labor, shortens the transportation cycle, improves production efficiency, and reduces transportation costs.

Product Name： FAW 30 Ton Tipper Truck
Driving Type： 6X4
Dump body Volume(cbm)： 18
Rated payload weight(kg)： 30000

Product Features

FAW 30 Ton Tipper Truck

A tipper truck refers to a vehicle that unloads goods on its own through hydraulic or mechanical lifting, also known as a dump truck. It consists of components such as car chassis, hydraulic lifting mechanism, cargo compartment, and power take-off device.

Tipper truck, is basically used to transport kinds of sand, soil, rock, ore, etc material.

Product feature

Faw 10 wheel dump chassis

High strength manganese steel dump box

30 ton payload capacity

Factory direct sale

Product parameters

Product Name	FAW 30 Ton Tipper Truck
Driving Type	6X4
Dump body Volume(cbm)	18
Rated payload weight(kg)	30000
Overall Dimension(mm)	8700x2480x3500
Dump body size(mm)	5600x2300x1400
Engine brand & model	FAW
Engine type	4 stroke,water-cooled, straight line 6 cylinders, diesel
Axle Quantity	3
Transmission Type	CA 9 forwards,1 reverse gear, manul
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	11.00R20, 10+1 spare
Cab	FAW J6P Flat proof, single sleepr, radio, air seat, A/C
Dump body material	High strength manganese steel
Main configuration	1. Side plate 6mm, floor plate 8mm. 2.Front mounted hydraulic lifting cylinder
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
