FAW Jiefang 3m³ sewage suction truck

Chassis configuration:

Jiefagn V5 cab, new interior design. Yunnei 102 horsepower, D20TCIF14 National VI engine, 5-speed gearbox, 2400mm wheelbase, oil brake, spring steel plate 4/5+2, 6.00-15 10PR tires, ABS, electric shut-off, 24V battery, electrically adjustable radio+MP3.

Product Name： FAW Jiefang 3m³ sewage suction truck
Driving Type： 4X2
Gross vehicle weight(Kg)： 4495(Kg)
Curb weight(Kg) ： 2650(Kg)

Product Features

FAW Jiefang 3m³ sewage suction truck

Sewage suction truck, also called sewage tanker truck, sewage truck, sewage suction tanker truck,vacuum sewage suction truck,suction truck, fecal suction truck, vacuum tank suction tanker truck etc .

Introduction

Suction sewage truck is a new type of environmental sanitation vehicle that collects, transfers, cleans, and transports sludge and sewage to avoid secondary pollution. The suction truck can self suction and discharge, with fast working speed, large capacity, and convenient transportation. It is suitable for collecting and transporting liquid substances such as feces, mud, and crude oil. The suction truck adopts a domestically advanced vacuum pump with high suction force and long suction distance, which is particularly suitable for the suction, transportation, and discharge of sediment in sewers, especially for large objects such as sewage mud, sludge, stones, bricks, etc.

Product parameters

Product Name	FAW Jiefang 3m³ sewage suction truck
Driving Type	4X2
Gross vehicle weight(Kg)	4495(Kg)
Curb weight(Kg)	2650(Kg)
Rated weight(kg)	1715(Kg)
Wheelbase(mm)	2400(mm)
Overall Dimension(mm)	5050×1880,1950×2250,2380,2480(mm)
Tank volume(cbm)	2.6m³ -3m³
Engine brand & model	D20TCIF14, Yunnei 102 horsepower
Displacement(L)/Power(kw)	1.99L
Axle Quantity	2
Transmission Type	5-speed gearbox
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	6.00-15LT 10PR, 6+1 spare
Cab	Jiefang V5 cab
Tank material	8mm carbon steel
Standard configuration	Oil water separator, water gas separator, hydraulic dumping device, special vacuum suction bump, volume pressure gauge,suction pipe, gravity valve, vacuum tank, connected vessels (fecal window), full-automatic anti overflow valve, hydraulic kit.
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
