Dongfeng 8X4 suction cleaning truck, 33m³ sewage suction truck

Dongfeng 6X4 sewage suction tanker truck, 22m³ sewage suction truck

Adopting Dongfeng 8X4 chassis, Longqing 465 horsepower engine, Fast 9-speed gearbox, vehicle size 12000X2550X3850MM, 8MM thickness, 10 cubic meters of clean water tank and 23 cubic meters of sewage tank. The left and right sides of the clean water tank are designed with fire hydrant water inlet for easy water intake, and the bottom is equipped with drainage outlet. The double Yao 600 flow high-pressure pump is equipped with air blowing water. The auxiliary engine adopts Weichai Power 460 horsepower engine, with a large filtration system, dual water inlet, two three claw filling ports for the sewage tank, self-made large anti overflow valve, hydraulic left and right winding discs at the rear, 600 hydraulic opening, equipped with arrow lights and LED lighting, internal drawing and internal binding steel plate, 150 side stealing drainage, raised top guardrail, thickened and reinforced rear bumper and winding disc, and external Tie steel plate

Product Name： Dongfeng 8X4 suction cleaning truck, 33m³ sewage suction truck
Driving Type： 8x4
Weight /Volume：
Tank volume(cbm)： 33m³

Product Features

Dongfeng 6X4 sewage suction tanker truck, 22m³ sewage suction truck

Sewage suction truck, also called sewage tanker truck, sewage truck, sewage suction tanker truck,vacuum sewage suction truck,suction truck, fecal suction truck, vacuum tank suction tanker truck etc .

Introduction

Suction sewage truck is a new type of environmental sanitation vehicle that collects, transfers, cleans, and transports sludge and sewage to avoid secondary pollution. The suction truck can self suction and discharge, with fast working speed, large capacity, and convenient transportation. It is suitable for collecting and transporting liquid substances such as feces, mud, and crude oil. The suction truck adopts a domestically advanced vacuum pump with high suction force and long suction distance, which is particularly suitable for the suction, transportation, and discharge of sediment in sewers, especially for large objects such as sewage mud, sludge, stones, bricks, etc.

Product parameters

Product Name	Dongfeng 8X4 suction cleaning truck, 33m³ sewage suction truck
Driving Type	8x4
Weight /Volume
Tank volume(cbm)	33m³
Rated payload weight(kg)	11300
Dimensions
Wheelbase(mm)	2050+4400+1350
Overall Dimension(mm)	12000x2550x3850
Engine
Engine brand & model	dongfeng, DDi11E465-60.
Displacement(L)/Power(kw)	10.8L/343kW
Chassis
Axle Quantity	4
Transmission Type	9 forward gears and 1 reverse gear
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	1100R20, 12 with a spare
Cab
Standard configuration	with sleepling berth
Air conditioning	YES
Performance parameter
Garbage container material	8mm carbon steel plate
Standard configuration	Oil water separator, water gas separator, hydraulic dumping device, special vacuum suction bump, volume pressure gauge,suction pipe, gravity valve, vacuum tank, connected vessels (fecal window), full-automatic anti overflow valve, hydraulic kit.
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
