13m³ Dongfeng D9 sewage suction truck

Chassis configuration:

The chassis adopts Dongfeng Dorica D9, 2315/half cab, Cummins 230 horsepower, 4500 wheelbase, Fast 8-speed, 295/80R22.5 vacuum tires, Dena axle, front axle 4.5T, rear axle 10T, 250 double-layer frame, dynamic rotation, clutch assist, electric door and window hollow lock, air conditioning, air brake, exhaust brake

Product Name： 13m³ Dongfeng D9 sewage suction truck
Driving Type： 4X2
Gross vehicle weight(Kg)： 18000(Kg)
Curb weight(Kg) ： 7880,8650(Kg)

Product Features

13m³ Dongfeng D9 sewage suction truck

Sewage suction truck, also called sewage tanker truck, sewage truck, sewage suction tanker truck,vacuum sewage suction truck,suction truck, fecal suction truck, vacuum tank suction tanker truck etc .

Introduction

Suction sewage truck is a new type of environmental sanitation vehicle that collects, transfers, cleans, and transports sludge and sewage to avoid secondary pollution. The suction truck can self suction and discharge, with fast working speed, large capacity, and convenient transportation. It is suitable for collecting and transporting liquid substances such as feces, mud, and crude oil. The suction truck adopts a domestically advanced vacuum pump with high suction force and long suction distance, which is particularly suitable for the suction, transportation, and discharge of sediment in sewers, especially for large objects such as sewage mud, sludge, stones, bricks, etc.

Product parameters

Product Name	13m³ Dongfeng D9 sewage suction truck
Driving Type	4X2
Gross vehicle weight(Kg)	18000(Kg)
Curb weight(Kg)	7880,8650(Kg)
Rated weight(kg)	9990,9925,9220,9155(Kg)
Wheelbase(mm)	4500(mm)
Overall Dimension(mm)	7880,7680,7480×2500×3600(mm)
Tank volume(cbm)	13m³
Engine brand & model	B6.2NS6B230, Cummins 230hp
Axle Quantity	2
Transmission Type	FAST 8-speed gearbox
Steering Type	LHD or RHD with power steering
Brake system	air brake
Tire Spec. & size	295/80R22.5 vacuum tire , 6+1 spare
Cab	Dongfeng D9 cab
Installation configuration	SK-15 water circulation pump, equipped with a fecal observation window, hand washing device, suction hose of 8 meters each, with oil-water separator, vacuum pressure gauge, anti overflow valve, hydraulic lifting of the tank body, hydraulic opening of the back cover, one DN100 feeding port, one DN150 discharging port, and one suction tank port
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
