Dayun G6 6X4 concrete mixer truck

Chassis configuration:

1. Engine: WP4.6NQ220E62 Weichai 220 horsepower engine
2. Tires: 10.00R20/18PR steel wire tire
3. Wheelbase: 3400+1350
4. Cab: Dayun G6 luxury body
5. Transmission: Fast Ten speed Transmission
6. Front axle: 5T front axle, rear axle: reinforced 11.5T double rear axle
7. Other: Standard includes central locking, remote key, electric doors and windows, shock absorber seats, driving recorder, and aluminum alloy fuel tank.





  • Product Name: Dayun G6 6X4 concrete mixer truck
  • Driving Type: 6X4
  • Total weight(kg): 24500(Kg)
  • Curb weight(kg): 10700(Kg)

Product Features

Dayun G6 6X4 concrete mixer truck

A concrete mixer truckis a specialized truck used to transport concrete for construction purposes; Due to its appearance, it is often referred to as a snail car. These types of trucks are equipped with cylindrical mixing drums to transport the mixed concrete. During transportation, the mixing drum will always rotate to ensure that the concrete being transported does not solidify. After transporting the concrete, it is usually washed with water inside the mixing drum to prevent hardened concrete from occupying space and reducing the volume of the mixing drum.

Concrete mixer truckis also called cement mixer truck, cacapity range from 3 cbm to 16 cbm, chassis brand option: dongfeng, howo,shacman, foton, faw, isuzu, lveco, etc.

Upper configuration:

1. Tank material: The tank body is made of manganese steel Q345, 4mm material, and the head is made of 6mm high-strength steel
2. Hydraulic system: Koyi reducer, Impop pump, motor. (optional according to user requirements)
3. Tank color: Regular color: white/red (can be customized according to user requirements)



Product parameters

Product Name Dayun G6 6X4 concrete mixer truck
Driving Type 6X4
Total weight(kg) 24500(Kg)
Curb weight(kg) 10700(Kg)
Rated weight(kg) 13990,14055(Kg)
Wheel base(mm) 3400+1350 (mm)
Overall Dimension(mm) 8330/8270X2450X3690 (mm)
Tank maximum diameter(mm) 2170(mm)
Tank length(mm) 4740(mm)
Engine brand & model WP4.6NQ220E62, Weichai 220hp
Axle Quantity 3
Transmission Type FAST 10-speed gearbox
Steering Type LHD or RHD with power steering
Tire Spec. & size 10.00R20/18PR steel wire tire, 10+1 spare
Cab Dayun G6 Luxury Body
Tank material Tank shell: 4mm Q345, tank head: 6mm Q345
Tank agitation capacity 5.99m³
Tank capacity 6m³
Stadard configuration The tank body is made of manganese steel Q345, 4mm material, and the head is made of 6mm high-strength steel Hydraulic system: Koyi reducer, Impop pump, motor.
Notice The above information is for reference only, and vehicles can be customized depending on your requirements.

Vehicle pictures
