Mercedes Benz Ouman 4X2 one to two flatbed obstacle clearing vehicle

Chassis configuration:

Driver's cabin: Mercedes Benz Ouman 2350mm wide body driver's cabin, luxurious interior, airbag seats
Wheelbase: 5750mm
Engine: Cummins 220 horsepower
Transmission: Fast 8-speed with synchronizer and power take-off
Rear axle: 10 ton level rear axle
Frame: Double layered I-beam
Leaf spring: 10/10+8 reinforced and thickened leaf spring
Tires; 10.00R20 steel wire tire
Other configurations: Four point suspension, airbag seats, air conditioning, cruise control, multifunction steering wheel, central locking system, electric doors and windows, remote key, air brake, cut-off air brake, power steering, ABS

Installation configuration:
One to two type, double-sided linkage operation device, using flat sinking technology, 10 ton upper loading, 8 ton hydraulic winch, 10 ton three section rear trailing arm, plate length of 8.3 meters (including 1.3 meter hydraulic flip tail plate), width of 2.55 meters, 8mm thick patterned plate, innovative and unique double vertical and horizontal cross brace, 16mm thick manganese plate slide track, reinforced double secondary beam, flat electrophoretic anti rust paint, 2 rear work lights, 1 toolbox, Foshan HZL oil cylinder.

Product Name： Mercedes Benz Ouman 4X2 one to two flatbed obstacle clearing vehicle
Driving Type： 4X2
Gross vehicle weight(Kg)： 18000(Kg)
Curb weight(Kg)： 10650,10150(Kg)

Product Features

Mercedes Benz Ouman 4X2 one to two flatbed obstacle clearing vehicle

An obstacle clearing vehicle (also called a wrecker, a breakdown truck, recovery vehicle or a breakdown lorry) is a vehicle used to move disabled,improperly parked, impounded, or otherwise indisposed motor vehicles. This may involve recovering a vehicle damaged in an accident, returning one to a drivable surface in a mishap or inclement weather, or towing or transporting one via flatbed to a repair shop or other location.

This vehicle is mainly used for road block removal , and its main specialized devices are flat plates, supporting arms, winches, steel wire ropes, and oil cylinders.

Product parameters

Product Name	Mercedes Benz Ouman 4X2 one to two flatbed obstacle clearing vehicle
Driving Type	4X2
Gross vehicle weight(Kg)	18000(Kg)
Curb weight(Kg)	10650,10150(Kg)
Lift weight(kg)	7655kg(Kg)
Cab	Mercedes Benz Ouman 2350mm wide body cabin, luxurious interior, airbag seats
Engine brand & model	F4.5NS6B220,Cummins 220 horsepower
Displacement(L)/Power(kw)	4.5L/162KW
Wheelbase(mm)	5750mm
Axle Quantity	2
Transmission Type	Fast 8-speed with synchronizer and power take-off
Steering Type	LHD or RHD with power steering
Brake system	Air brake
Tire Spec. & size	10.00R20 steel wire tire, 6+1 spare
Overall Dimension(mm)	10570,10520,9765×2550,2500×2820,2790,3150(mm)
Platform	Board length 8.3 meters (including 1.3 meters hydraulic flip tail board), width 2.55 meters
Crane specification	without crane
Standard configuration	/
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
