4X2 SHACMAN L5000 15m³ greening sprinkler truck

Chassis configuration:

1. Engine: D4.5NS6B240,Cummins 240hp

2.Transmission type: Fast 8-speed gearbox

3.Tyre:1O.00R20, 6+1 spare

4.Wheelbase:4000(mm)

5 Other: Electric glass, with original ABS, airbag seats, original air conditioning, central locking with remote key, driving recorder

Installation configuration:
1.The tank body is about 15 cbm.
2.The side lights are electrified, and two red width indicator lights are standard above the tail of the tank.
3.The standard front spray is duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.

Product Name： 4X2 SHACMAN L5000 15m³ greening sprinkler truck
Driving type： 4X2
Engine Model： D4.5NS6B240
Engine horsepower： Cummins 240HP

Product Features

4X2 SHACMAN L5000 15m³ greening sprinkler truck

Greening sprinkler truck, also known as greening sprinkler truck or garden greening sprinkler truck, is used for garden seedling protection, urban greening, factory dust removal, fire sprinkler, and road flushing. Greening sprinkler trucks have the function of spraying in different directions.

Parameters

Product Name	4X2 SHACMAN L5000 15m³ greening sprinkler truck
Driving type	4X2
Engine Model	D4.5NS6B240
Engine horsepower	Cummins 240HP
Engine displacement	4.5L
Gearbox	Fast 8-speed gearbox
Tire specification	10.00R20, 6+1 spare
Wheel base (mm)	4000(mm)
Gross vehicle weight(Kg)	18000(kg)
Curb weight(Kg)	7250,6800(kg)
Rated weight(Kg)	10620,10555,11070,11005(kg)
Vehicle dimensions (mm)	7850,7450x2550,2500x3120,3000(mm)
Tank volume(cbm)	15
Fuel type	diesel
Emission standard	Euro 6 (option:Euro3/4/5)
Water pump model	60/90
Tank material	Q235 carbon steel,5mm
Additional configuration	Electric cannon, reversing camera, cylinder, pneumatic valve, toolbox, arrow warning light
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
