Jiefang 7cbm road maintenance vehicle

Chassis configuration:
1. Engine: 490PLUS2, Yunnei 140hp

2.Transmission type: 5 forward gears and 1 reverse gear

3.Tyre: 7.00R16 steel wire tire

4.Wheelbase:3300mm

5 Other: Air brake, original air conditioning, electric doors and windows, central locking system, driving recorder.
Installation configuration:
1.The tank body is about 7 cbm.
2.The side lights are electrified, and two red width indicator lights are standard above the tail of the tank.
3.The standard front spray is duckbill straight jet, and the standard rear spray allows users to adjust the offset position according to their own needs.

Product Name： Jiefang 7cbm road maintenance vehicle
Engine Model： 490PLUS2
Engine horsepower： Yunnei 140hp
Engine displacement： 2.46L

Product Features

Product Introduction

A road maintenance truck is a specialized vehicle designed to support the upkeep and repair of roadways, ensuring they remain safe and functional for public use. These trucks are equipped with a variety of tools and features tailored to address the specific needs of road maintenance tasks. They play a crucial role in municipal and state infrastructure management, handling everything from minor repairs to significant construction efforts.

Main Parameter

Product Name	Jiefang 7cbm road maintenance vehicle
Engine Model	490PLUS2
Engine horsepower	Yunnei 140hp
Engine displacement	2.46L
Gearbox	5 forward gears and 1 reverse gear
Tire specification	7.00R16 steel wire tire
Wheel base (mm)	3300
Gross vehicle weight(Kg)	4495
Curb weight(Kg)	3630
Rated weight(Kg)	735
Vehicle dimensions (mm)	5998X2060X2700
Tank volume(cbm)	7
Fuel type	diesel
Emission standard	Euro 6 (option:Euro3/4/5)
Water pump model	50/50
Tank material	Q235 carbon steel
Additional configuration	Electric cannon, reversing camera, cylinder, pneumatic valve, toolbox, arrow warning light
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
