Dongfeng 5 ton water tank fire truck

Chassis configuration:

1. Engine: YCY30165-60

2.Transmission type: 5-speed gearbox

3.Tyre: 245/70R19.5,6 with a spare

4.Wheelbase:3800,3950,4050,4100,4400,3600,4700(mm)

5.Other: Central control door lock, electric doors and windows, ABS, air conditioning.
Installation configuration:

Equipped with CB10/30 fire pump and PS30 fire monitor, with a flow rate of 30L/S/1.0Mpa and a range of over 55 meters

Product Name： Dongfeng 5 ton water tank fire truck
Driving Type： 4X2
Total weight（Kg)： 11300(Kg)
Curb weight(kg)： 6050(Kg)

Product Features

Dongfeng 5 ton water tank fire truck

A fire engine, also known as a fire truck, refers to a vehicle designed and manufactured according to needs, suitable for firefighters to use, equipped with various fire-fighting equipment or agents, for firefighting, auxiliary firefighting, or firefighting rescue. It is the main tool for firefighting and is also the most basic mobile firefighting equipment.

Water tank fire truck: The fire extinguishing agent equipped on this vehicle is mainly water. It has a large capacity water storage tank, water gun, water cannon, etc., which can be used for extinguishing conventional fire accidents. It can be directly extinguished using a water source, or it can be directly extinguished by absorbing water from the water source. It can also be used to supply water to other fire extinguishing spraying equipment in the fire scene. Suitable for extinguishing general fire accidents, it is a firefighting vehicle regularly used by the public security fire brigade.

Product parameters

Product Name	Dongfeng 5 ton water tank fire truck
Driving Type	4X2
Total weight（Kg)	11300(Kg)
Curb weight(kg)	6050(Kg)
Rated weight(kg)	4800(Kg)
Wheel base(mm)	3800,3950,4050,4100,4400,3600,4700(mm)
Overall dimension(mm)	6960×2200×2810(mm)
Engine brand & model	YCY30165-60
Displacement(L)/Power(kw)	3L/121KW
Axle Quantity	2
Transmission Type	5-speed gearbox
Steering Type	LHD or RHD with power steering
Brake system	air brake
Tire Spec. & size	245/70R19.5,6 with a spare
Cab	Central control door lock, electric doors and windows, ABS, air conditioning.
Extinguishing Media	water/foam/dry-powder
Tank material	Carbon steel or stainless steel and aluminum alloy plate
Tank volume（L）	5000
Configuration and performance	Equipped with CB10/30 fire pump and PS30 fire monitor, with a flow rate of 30L/S/1.0Mpa and a range of over 55 meters
Onboard equipment	Onboard equipment Fire hose, water injection hose, DC water gun, multifunctional water gun, dry powder fire extinguisher, water collector, water separator, suction pipe wrench, rubber hammer, protective belt bridge, above ground fire hydrant wrench, underground fire hydrant wrench, water hose strap, water hose hook, fire axe, fire suction pipe, suction pipe filter, reducer interface
Notice	The above information is for reference only, and vehicles can be customized depending on your requirements.
